Resin Cast Straight Joint and Termination Kit is used for making durable, insulated, and moisture-proof joints or terminations for low-voltage (LV) and medium-voltage (MV) power cables. It uses a special two-part polyurethane or epoxy resin poured into a mould to completely encapsulate and seal the cable connection.
FEATURES:-
Excellent electrical insulation — prevents partial discharge.
Strong environmental sealing — suitable for waterlogged and contaminated areas.
Low maintenance — once cured, it becomes a permanent seal.
-Harsh industrial and coastal environments.
-Oil & gas, chemical plants, and renewable energy sites.
Kit selection chart
| Cable Size (Sq.mm.) | Kit Code |
|---|---|
| 3x25-50 | HCS-11 |
| 3x70-120 | HCS-12 |
| 3x150-240 | HCS-13 |
| 3x300-400 | HCS-15 |
| Cable Size (Sq.mm.) | Kit Code |
|---|---|
| 3x25-50 | HCS-41 |
| 3x70-120 | HCS-42 |
| 3x150-240 | HCS-43 |
| 3x300-400 | HCS-45 |
| Cable Size (Sq.mm.) | Kit Code |
|---|---|
| 3x50-95 | HCS-51 |
| 3x120-185 | HCS-52 |
| 3x240-400 | HCS-53 |
Resin Cast Straight Joint and Termination Kit is designed for 3-core power cables up to 36 kV with XLPE, PVC, or PILC insulation. Kit provides complete electrical insulation and mechanical protection using high-dielectric-strength resin encapsulation. It ensures a moisture-proof, corrosion-resistant, and mechanically robust solution for underground, outdoor, or industrial installations.
FEATURES
-Suitable for 3-core XLPE, PVC, or PILC cables up to 36 kV
-High-dielectric-strength resin provides excellent electrical insulation
-Complete moisture sealing – prevents water ingress in underground or submerged installations
-Corrosion and chemical resistant – withstands acids, alkalis, oils, and industrial contaminants
-No heat source required – safe for use in hazardous or flammable environments
-Robust mechanical protection – resists impact, vibration, and compression
-Compatible with copper and aluminium conductors
-Maintenance-free once installed
| Cable Size (Sq.mm.) | Kit Code |
|---|---|
| 3x25-50 | HCS-11 |
| 3x70-120 | HCS-12 |
| 3x150-240 | HCS-13 |
| 3x300-400 | HCS-15 |
| Cable Size (Sq.mm.) | Kit Code |
|---|---|
| 3x25-50 | HCS-41 |
| 3x70-120 | HCS-42 |
| 3x150-240 | HCS-43 |
| 3x300-400 | HCS-45 |
| Cable Size (Sq.mm.) | Kit Code |
|---|---|
| 3x50-95 | HCS-51 |
| 3x120-185 | HCS-52 |
| 3x240-400 | HCS-53 |
