Resin Cast joint and termination 1/2/2/3.5/4 Core upto 11 KV For XLPE/PVC/PILC Cable

Resin Cast joint and termination 1/2/3/3.5/4 Core upto 1.1 kv for XLPE/PVC/PILC Cable

Electrical integrity: Two-part epoxy/polyurethane insulating resin with high dielectric strength and low partial discharge—designed for medium-voltage use up to 36 kV.
Mechanical robustness: Rigid cast body resists vibration, impact and soil stress.
Chemical/UV resistance: Oil-, salt-, and hydrolysis-resistant; UV-stable outer shell for outdoor terminations.
Universal compatibility: Works with XLPE, PVC and PILC (with sheath/lead continuity accessories).
Armour & screen continuity: Dedicated earthing kits and constant-force springs/braids ensure low-resistance bonds.
Simple installation: Pre-measured resin, transparent mould, integrated flow channels; no special heat tools required.
Fire & safety: Halogen-free, low-smoke components (where applicable); isocyanate-safe packaging.

OUTDOOR END TERMINATION		INDOOR END TERMINATION		STRAIGHT THROUGH JOINT
Cable Size	Kit Code	Cable Size	Kit Code	Cable Size	Kit Code
RESIN CAST TYPE: 3.3 KV (UE/E) XLPE & 6.6 KV/ 3.3 KV PVC Cable
1X150/185	COX-7	1X150/185	CIX-7	1X150/185	CSX-7
1X225/240/300	COX-8	1X225/240/300	CIX-8	1X225/240/300	CSX-8
1X400/500/630	COX-9	1X400/500/630	CIX-9	1X400/500/630	CSX-9
1X800/1000	COX-10	1X800/1000	CIX-10	1X800/1000	CSX-10
RESIN CAST TYPE: 6.6 KV (E) XLPE & 11 KV (E) / 6.6 KV (UE) PVC Cable
1X150/185	CXO-28	1X150/185	CXI-28	1X150/185	CXS-28
1X225/240/300	CXO-29	1X225/240/300	CXI-29	1X225/240/300	CXS-29
1X400/500/630	CXO-30	1X400/500/630	CXI-30	1X400/500/630	CXS-30
1X800/1000	CXO-30A	1X800/1000	CXI-30A	1X800/1000	CXS-30A
